PCB Production Line · Machine #02
Circular Edge Grinder
Model: Auto edge-grinding line
Automatic grinding of PCB edges after cutting, 4-stage grinding + auto load/unload.
Request a quoteTechnical Parameters
| Footprint | L3950 × W3200 × H1100 mm |
|---|---|
| Plate thickness | 0.4–3.0 mm |
| Board size | Max 730 × 730 mm / Min 230 × 230 mm |
| Transmission | 12 m/min, ~16 PNL/min |
| Material | FR-4, FR-1, CEM-1, CEM-3 |
| Power | 3-phase / 380 V / 5 kW |
This is a parameter-overview page. A more detailed product page with full specifications, optional configurations, and process recommendations is being prepared. In the meantime, please contact our engineers for the full datasheet and pricing.
