GREEN LASER MARKING MACHINE


green laser marking machine



Features:The output wavelength of green laser marking machine is 532nm laser. The characters are smaller focusing spot, more concentrated energy, higher elector-optical conversion efficiency and better beam quality. It can process on the material which have high reflective and high penetration for Infrared wavelength.

Contact Us Regarding Product

Applications:
Foods, fruit, vegetables, eggs;
Ceramic, plastic;
Electronic components, integrated circuits (IC), PCB;
Electrical appliances, communication products, signage;
Sanitary ware, hardware products;
Tool accessories, precision instruments;
PVC pipe, medical instruments.



Type GE1 Table,GE2 Universal
Laser type/Wavelength AO/532nm
Laser power 3W 6W
Beam quality M2 <1.5
Pulse width ≤5ns
Power stability>4h +/-5% rms
Laser mode Near TEM00
Marking size 100mm x 100mm
180mm x 180mm or Order
Marking depth Adjustable
Marking line speed 7000mm/s
Marking width Min 0.01mm(30μm)
Marking character Min 0.1mm
Repeat marking accuracy ≤10μ/rad
Power total ≤800W
Power supply AC 220V/50Hz
Outsize 570*840*1240mm(Differance by types)


Laser Marking Sample


 plastic laser marking
plastic laser marking

plastic laser marking
plastic laser marking

 plastic laser marking
plastic laser marking

 plastic laser marking
plastic laser marking
